Product Introduction
En slip flange is a plain slip-on flange, made totally to the EN1092-1 Type 12 standard. En slip flange used to make detachable joints - between pipes, or between pipes and equipment. We have forged and regular slip-on versions, and it works well for pressure resistance, temperature tolerance, and corrosion resistance.
You'll see the En slip flangeused in all kinds of fields: oil, chemical, natural gas, power, shipbuilding and marine engineering, municipal work (water supply & drainage, heating, gas), sewage treatment, building fire protection, and machinery manufacturing.
Product Parameters
|
Parameter |
Specification |
|
Execution Standard |
EN1092-1 type12 |
|
Product Types |
Forged, Slip-On Flange |
|
Size Range |
DN15-DN600 |
|
Pressure Rating |
PN6-PN100 |
|
Connection Type |
Butt welding, bolted connection |
|
Surface Treatment |
Rust preventive oil, hot-dip galvanizing, sandblasting, acid washing |
|
Materials |
P250GH, P245GH, P280GH, 13CrMo4-5, 11CrMo9-10, P355NH, X10CrMoVNb9-1, X2CrNi18-9, X6CrNiTi18-1, X2CrNiMo17-12-2 |
|
Packaging Method |
Wooden crate, Wooden pallet |
|
Supply Capacity |
2000 tons/month |
|
Wall thickness and end preparation EN 1092-1 |
||||||||||||||||
|
Wall thickness for flange type 11 |
||||||||||||||||
|
ψ A |
PN2.5 |
PN6 |
PN10 |
PN16 |
PN25 |
PN40 |
PN63 |
PN100 |
||||||||
|
S |
Sp |
S |
Sp |
S |
Sp |
S |
Sp |
S |
Sp |
S |
Sp |
S |
Sp |
S |
Sp |
|
|
17.2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
|
21.3 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
3.2 |
2 |
|
26.9 |
2.3 |
2.3 |
2.3 |
2.3 |
2.3 |
2.3 |
2.3 |
2.3 |
2.3 |
2.3 |
2.3 |
2.3 |
2.6 |
2.3 |
3.2 |
2.3 |
|
33.7 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
3.6 |
2.6 |
|
42.4 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.9 |
2.6 |
3.6 |
2.9 |
|
48.3 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.6 |
2.9 |
2.9 |
3.6 |
3.2 |
|
60.3 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
4 |
3.2 |
4 |
3.6 |
|
76.1 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
2.9 |
4 |
3.6 |
4 |
4 |
|
88.9 |
3.2 |
3.2 |
3.2 |
3.2 |
3.2 |
3.2 |
3.2 |
3.2 |
3.2 |
3.2 |
3.2 |
3.2 |
4.5 |
4 |
5 |
5 |
|
114.3 |
3.6 |
3.6 |
3.6 |
3.6 |
3.6 |
3.6 |
3.6 |
3.6 |
3.6 |
3.6 |
3.6 |
3.6 |
4.5 |
4.5 |
5.6 |
5.6 |
|
139.7 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
5.6 |
5.6 |
6.3 |
6.3 |
|
168.3 |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
4.5 |
6.3 |
6.3 |
8 |
8 |
|
219.1 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
7.1 |
7.1 |
8.8 |
8.8 |
|
273.0 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
6.3 |
7.1 |
7.1 |
7.1 |
7.1 |
8.8 |
8.8 |
10 |
10 |
|
323.9 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
8 |
8 |
8 |
8 |
11 |
10 |
12.5 |
12.5 |
|
355.6 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
8 |
8 |
8 |
8 |
8.8 |
8.8 |
12.5 |
10 |
14.2 |
14.2 |
|
406.4 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
8 |
8 |
8.8 |
8.8 |
11 |
11 |
14.2 |
11 |
16 |
16 |
|
457 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
8 |
8 |
8.8 |
8.8 |
12.5 |
12.5 |
||||
|
508 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
7.1 |
8 |
8 |
10 |
10 |
14.2 |
14.2 |
||||
|
610 |
7.1 |
7.1 |
7.1 |
7.1 |
8 |
7.1 |
10 |
8.8 |
11 |
11 |
16 |
16 |
||||
|
711 |
7.1 |
7.1 |
8 |
7.1 |
8.8 |
8 |
10 |
8.8 |
14.2 |
12.5 |
||||||
|
813 |
7.1 |
7.1 |
8 |
7.1 |
8.8 |
8 |
12.5 |
10 |
16 |
14.2 |
||||||
|
914 |
7.1 |
7.1 |
8 |
7.1 |
12.5 |
10 |
12.5 |
10 |
17.5 |
16 |
||||||
|
1016 |
7.1 |
7.1 |
8 |
7.1 |
12.5 |
10 |
12.5 |
10 |
20 |
17.5 |
||||||
|
1219 |
8 |
7.1 |
8.8 |
8 |
12.5 |
11 |
14.2 |
12.5 |
||||||||
|
1422 |
8 |
7.1 |
8.8 |
8 |
14.2 |
12.5 |
16 |
14.2 |
||||||||
|
1626 |
8.8 |
8 |
10 |
9 |
16 |
14.2 |
17.5 |
16 |
||||||||
|
1829 |
10 |
10 |
11 |
10 |
17.5 |
16 |
20 |
17.5 |
||||||||
|
2032 |
11 |
10 |
12.5 |
11 |
17.5 |
16 |
22 |
20 |
||||||||
|
2235 |
11 |
10 |
14 |
12.5 |
20 |
18 |
||||||||||
|
2438 |
11 |
10 |
15 |
14.2 |
22.2 |
20 |
||||||||||
|
2620 |
11 |
10 |
16 |
14.2 |
25 |
22.2 |
||||||||||
|
2820 |
11 |
10 |
17 |
16 |
25 |
22.2 |
||||||||||
|
3020 |
11 |
10 |
20 |
16 |
32 |
24 |
||||||||||
|
3220 |
11 |
10 |
20 |
16 |
||||||||||||
|
3420 |
11 |
10 |
22 |
17.5 |
||||||||||||
|
3620 |
11 |
10 |
22 |
17.5 |
||||||||||||
|
3820 |
11 |
10 |
||||||||||||||
|
4020 |
11 |
10 |
||||||||||||||
Product Advantages
Standard and solid quality
En slip flange dimensions are accurate, and it holds up well under high pressure and high temperatures.
01
Multiple material choices
Carbon steel, alloy steel, stainless steel options, fit different media, corrosion and temperature needs.
02
Install
Slip-on design makes pipe alignment simple, cuts down on installation time and labor costs.
03
Great sealing
Precise machining and steady sealing structure, stops leaks, keeps operations safe at high pressure.
04
Main Applications
Oil & Gas
En slip flange used for connecting high-pressure pipelines, valve stations, compressor units.
Chemical & Power
Fits high-temperature, corrosion-resistant pipelines for reactors, heat exchangers, boilers.
Municipal & Machinery
Works for urban water supply/drainage, heating, gas, sewage treatment, building fire protection; also used on pumps, compressors, storage tanks.
